Minimum Requirements

• Visual Studio Code or Visual Studio 2023
• C# for Visual Studio Code (latest version)
• .NET 7.0.2 SDK

Installation Process of .NET SDK.

Step1: Please visite the Official Web Site of the ..NET SDK

Step2: Click on the Download .NET SDK. button

Step3: Now your .NET SDK file has downloaded and installed in your computer.

Instalation Process Of ASP.Net Core7 & Mvc5

Here we are using "ASP.Net Core7 & Mvc5 " download

If you know how to create ASP.Net Core7 & Mvc5 project you can skip this step.

• Assuming that you have already installed .NET SDK in your computer.
• First, you need to create an environment at your project location For example:C:\project\projectname>
     Use for Asp.Net Mvc5
• This project folder path can be used to open the command.Now execute the command dotnet new mvc -o Projectname It creates a new ASP.NET MVC5
       project in the Project Name folder.
     Use for Asp.Net Core7
• This project folder path can be used to open the command.Now execute the command dotnet new webapp -o Projectname It creates a new ASP.NET Core7
       project in the Project Name folder.
• Trust the HTTPS development certificate by running the following command dotnet dev-certs https --trust .
• Now you are sucessfully installed ASP.Net Core7 & Mvc5 project.

Visual Studio Code

• If you are using Visual Studio Code.
• Go to your root project location path, then open the project file in your editor.
• Open the command prompt, then use " cd /path-to-your-project ".
• Enter the command dotnet watch run to get ASP.Net Core7 & Mvc5 development server.

Visual Studio

• If you are using Visual Studio.
• Open the Visual studio, then click on "Open a Project or Solution."
• Go to your root project location path, then you will see inside the folder projectname.csproj. Select it, and then open the project file.
• Now, press the key F5 to get ASP.Net Core7 & Mvc5 development server.

The Basic Structure Of ASP.NET Mvc5 Project


											├── bin/
											|   └── debug/
											|       └── net7.0
											├── Controllers/
											├── Models
											├── obj
											├── Properties
											├── Views
											├── wwwroot
											├── appsettings.Development.json
											├── appsettings.json
											├── gulpfile.js
											├── package-lock.json
											├── package.json
											├── program.cs
											├── sparic.csproj
											├── sparic.csproj.user
											└── sparic.sln



• First, unzip the project folder that you received from us.
• Navigate as shown Example: C:\projectname\views in that project folder in will have 11 folders and in 110+ cshtml files.
• Navigate as shown Example: C:\projectname\ Controllers in that project folder will have 10 Controller.cs pages.
• Navigate as shown Example: C:\projectname\views\shared\layouts Open folder there you will find _app-header.cshtml, _app-sidebar.cshtml and _footer.cshtml, and _switcher.cshtml, files and etc..,.
• Here _Layout.cshtml file is the base file for all the cshtml pages.
• Here _Layout1.cshtml file is the base file for all custom pages ex: error400.cshtml, error500.cshtml,and error503.cshtml, etc..,
• Here _Layout2.cshtml file is the base file for all custom pages ex: forgot.cshtml, lockscreen.cshtml, etc..,
• Here _Layout3.cshtml file is the base file for SwitcherPage.cshtml page.

The Basic Structure Of ASP.NET Core7 Project


											├── bin/
											|   └── debug/
											|       └── net7.0
											├── obj
											├── Pages
											├── Properties
											├── wwwroot
											├── appsettings.Development.json
											├── appsettings.json
											├── gulpfile.js
											├── package-lock.json
											├── package.json
											├── program.cs
											├── sparic.csproj
											├── sparic.csproj.user
											└── sparic.sln




• First, unzip the project folder that you received from us.
• Navigate as shown Example: C:\projectname\Pages in that project folder in will have 11 folders and in 110+ cshtml files and 11 + cshtml.cs files.
• Navigate as shown Example: C:\projectname\Pages\shared\layouts Open folder there you will find _app-header.cshtml, _app-sidebar.cshtml and _footer.cshtml, and _switcher.cshtml, files and etc..,.
• Here _Layout.cshtml file is the base file for all the cshtml pages.
• Here _Layout1.cshtml file is the base file for all custom pages ex: error400.cshtml, error500.cshtml,and error503.cshtml, etc..,
• Here _Layout2.cshtml file is the base file for all custom pages ex: forgot.cshtml, lockscreen.cshtml, etc..,
• Here _Layout3.cshtml file is the base file for SwitcherPage.cshtml page.

How to run ASP.Net Core7 & Mvc5 development server

Visual studio code

• First, unzip the project folder that you received from us.
• Go to your root project location path, then open the project file in your editor.
• Open the command prompt, then use " cd /path-to-your-project ".
• Now execute the command: dotnet watch run to getASP.Net Core7 & Mvc5 development server.

Visual studio

• First, unzip the project folder that you received from us.
• Go to your root project location path, then open the project file.
• Just double click on the file sparic.sln inside the project folder.
• Now, press the keyF5 to getASP.Net Core7 & Mvc5 development server.

Software Versions Used:

• .Net fremework :4.8
• C# for Visual Studio Code : (latest version)
• .NET : 7.0.102

ASP .Net Mvc5 Over All Folder Structure

									├── bin/
									|   └── Debug/
									|       └── net7.0/
									|           ├── appsettings.Development.json
									|           ├── appsettings.json/
									|           ├── package-lock.json
									|           ├── package.json
									|           ├── sparic.deps.json/
									|           ├── sparic.dll
									|           ├── sparic.exe
									|           ├── sparic.pdp
									|           ├── sparic.runtimeconfig.json
									|           └── sparic.staticwebassets.runtime.json
									├── Controllers
									|   └── 10 Controller.cs (files)
									├── Modals
									|   └── ErrorViewModel.cs
									├── obj
									|   ├── Debug
									|   ├── project.assets.json
									|   ├── project.nuget.cache
									|   ├── sparic.csproj.nuget.dgspec.json
									|   ├── sparic.csproj.nuget.g.props
									|   └── sparic.csproj.nuget.g.targets
									├── Properties
									|   └── launchSettings.json
									├── Views/
									|   ├── Shared__
									|   |   ├── _Layout.cshtml
									|   |   ├── _Layout.cshtml.css
									|   |   ├── _Layout1.cshtml
									|   |   ├── _Layout2.cshtml
									|   |   ├── _Layout3.cshtml
									|   |   ├── _ValidationScriptsPartial.cshtml
									|   |   ├── Error.cshtml
									|   |   └── layouts
									|   |       ├── _app-header.cshtml
									|   |       ├── _app-header1.cshtml
									|   |       ├── _app-sidebar.cshtml
									|   |       ├── _footer.cshtml
									|   |       ├── _sidebar-right.cshtml
									|   |       └── _switcher.cshtml
									|   ├── 11 Folders
									|   |   └── 110 + .cshtml (Files)
									|   ├── _ViewImports.cshtml
									|   └── _ViewStart.cshtml
									├── wwwroot/
									|   ├── assets/
									|   |   ├── css/
									|   |   ├── iconfonts/
									|   |   ├── images/
									|   |   ├── js/
									|   |   ├── plugins/
									|   |   ├── scss/
									|   |   └── switcher/
									|   ├── css
									|   |   └── site.css
									|   ├── js
									|   |   └── site.js
									|   └── lib
									|   |    ├── bootstrap
									|   |    ├── jquery
									|   |    ├── jquery-validation
									|   |    └── jquery-validation-unobtrusive
									|   └── favicon.ion
									├── appsettings.Development.json
									├── appsettings.json
									├── gulpfile.js
									├── package-lock.json
									├── package.json
									├── program.cs
									├── sparic.csproj
									├── sparic.csproj.user
									└── sparic.sln


Asp .Net Core7 Over All Folder Structure

									├── bin/
									|   └── Debug
									|       └── net7.0
									|           ├── appsettings.Development.json
									|           ├── appsettings.json
									|           ├── package-lock.json
									|           ├── package.json
									|           ├── sparic.deps.json
									|           ├── sparic.dll
									|           ├── sparic.exe
									|           ├── sparic.pdb
									|           ├── sparic.runtimeconfig.json
									|           └── sparic.staticwebassets.runtime.json
									├── obj
									|   ├── Debug
									|   ├── project.assets.json
									|   ├── project.nuget.cache
									|   ├── sparic.csproj.nuget.dgspec.json
									|   ├── sparic.csproj.nuget.g.props
									|   └── sparic.csproj.nuget.g.targets
									├── Pages
									|   ├── Shared__
									|   |   ├── _Layout.cshtml
									|   |   ├── _Layout.cshtml.css
									|   |   ├── _Layout1.cshtml
									|   |   ├── _Layout2.cshtml
									|   |   ├── _Layout3.cshtml
									|   |   ├── _ValidationScriptsPartial.cshtml
									|   |   └── layouts
									|   |       ├── _app-header.cshtml
									|   |       ├── _app-header1.cshtml
									|   |       ├── _app-sidebar.cshtml
									|   |       ├── _footer.cshtml
									|   |       ├── _sidebar-right.cshtml
									|   |       └── _switcher.cshtml
									|   ├── 11 Folders
									|   |   ├── 110 + .cshtml (Files)
									|   |   └── 11 .cshtml.cs (Files)
									|   ├── _ViewImports.cshtml
									|   ├── _ViewStart.cshtml
									|   ├── Error.cshtml
									|   ├── Error.cshtml.cs
									|   ├── Index.cshtml
									|   ├── Index.cshtml.cs
									|   ├── Privacy.cshtml
									|   └── Privacy.cshtml.cs
									├── Properties
									|   └──launchSettings.json
									├── wwwroot
									|   ├── assets
									|   |   ├── css
									|   |   ├── iconfonts
									|   |   ├── images
									|   |   ├── js
									|   |   ├── plugins
									|   |   ├── scss
									|   |   └── switcher
									|   ├── css
									|   |   └── site.css
									|   ├── js
									|   |   └── site.js
									|   └── lib
									|   |    ├── bootstrap
									|   |    ├── jquery
									|   |    ├── jquery-validation
									|   |    └── jquery-validation-unobtrusive
									|   └── favicon.ion
									├── appsettings.Development.json
									├── appsettings.json
									├── gulpfile.js
									├── package-lock.json
									├── package.json
									├── Program.cs
									├── sparic.csproj
									├── sparic.csproj.user
									└── sparic.sln
